AZA 0889 COLOUR STANDARD CHART
BS 1377:3
The chart provides a simple method for soil classification by of determining the color of soil specimens. Test set consists of 7 constant hue charts covering a total of 196 colors. The color chart and the diagram are fitted in a pocket size binder. Supplied complete with a tropical soil color chart, set of 2 which can be fitted into the binder.
Category: Soil
Related products
AZA 0850 LINEAR SHRINKAGE MOULD
AZA 0852 SEMI AUTOMATIC CONE PENETROMETER
AZA 0854 LIQUID LIMIT DEVICE (MOTORISED)
AZA 0858 SOIL HYDROMETER
IS 2720 (PART-VI),BS 1377-2
Specification:
Used for grain size analysis of soils where more than 10% of the material
will pass through 75 microns B.S. sieve. Manufactured from clear
transparent glass having uniform clarity throughout the upper end on which
density scale is engraved. The scale range is 0.995 to 1.030 density
(gms./cc) at 270C smallest division on the scale is 0.0005.
Note: Hydrometer for other liquids also available.
AZA 0859 SAND EQUIVALENT TEST SET
- Evaluates relative proportion of sand vs clay/silt in fine aggregates
- Complies with ASTM D2419 and IS 2720 standards
- Includes graduated cylinder, irrigator tube, siphon assembly
- Portable and easy to operate in field or lab
- Improves quality control in construction and roadwork
- Ideal for geotechnical and civil testing laboratories
- Optional : Stock solution can be supplied at an extra cost
AZA 0869 POCKET PENTROMETER
ASTM D 1558 D 2573
This instrument is used to estimate approximate unconfined
compressive strength and the estimation to shear strength of soil
Cohesive soils can also be classified in terms of consistency
using this Penetrometer. This is a handy and convenient
instrument.
Specification:
It consists of a light weight barrel assembly with a polished and
ground steel loading piston plunger. A direct reading scale is
engraved on the piston barrel and indicates load in kg. / sq.
cm. A maximum load indicator ring is provided on the
penetration plunger. The calibrated spring is heat treated and
plated for rust resistance. The barrel diameter is 20mm and the
length 150mm. Supplied with carrying case
AZA 0870 VICKSBERG PENTROMETER (PROVING RING TYPE)
This is fork determining the bearing capacity of sub grades or
for compaction control. It also used for rapidly of soils in
shallow exploration work.
Specification:
Consists of a study handle under. Which is fixed a sensitive
proving ring. An extension piece is fixed to the bottom of the
proving ring and carries a detachable penetration cone at its
tip. Proving ring capacity 100 kg (1kn) and 0.002mm dial
gauge provided indicates the penetration load applied.
An optical viewer is provided to facilitate reading the dial
gauge by the operator. Simplified for single person operation.
A calibration chart is provided for the proving ring. Instrument is
complete in a wooden carrying case.
AZA 0873 SPEEDY MOISTURE ZI 3027 METER (D2 LARGE)
- Speedy Moisture Meter: Utilizes the calcium carbide method for swift and precise moisture content determination.
- D2 Large Capacity: Designed for larger sample sizes, enhancing representativeness and accuracy for broader material types.
- Field Ready: Ideal for on-site field testing of soils, aggregates, sand, and other granular materials.
- Portable & Self-Contained: Operates without external power, making it perfect for remote locations.
- Rapid Analysis: Provides immediate results for efficient decision-making and quality control.
- Azalab Quality: Robust ZI 3027 frame ensures durability and reliable performance in demanding environments.
