AZA 1061 HEATING MANTLE

Different sizes made up of Sizes: 10” x 12”, 12” x 14”, 18” x 14”, 8” x 10”, 19” x 24”

This range of ovens is designed for drying large quantities of soil and aggregate samples and maintains temperature in accordance with most B.S. and ASTM requirements. The 225 Lts. and 425 Lts. are economy models constructed with coated mild steel exterior and Stainless Steel coated interior chamber, which is both durable and corrosion resistant. These units meet the requirements of BS 1377 and are ideal for on-site laboratories and general soil and aggregate testing. Options And Accessories: ! Dial thermometer with collar fixing for door ! Heavy duty shelves (on Request at an extra price) ! Color of the Oven (Only on qty. greater than 3 Units) Specifications: ! The larger soil drying ovens are constructed with mild steel and powder coated exterior and Stainless Steel coated chamber which is both durable and corrosion resistant. ! All Sizes of Oven are fitted with a (PID Controller) having a microprocessor digital control as standard. ! All units comes with MCB tripping device in cases of any short circuit, overloading of voltage and Low voltage cut off. Wiring of heaters can be connected / dis-connected removing the side panels of the Oven. ! Caster wheels with locking arrangement are fitted below the Oven for easy movability of the unit from one place to another. Door locking arrangement is very easy & convenient with lever to lock & unlock with half turn lever ! A Safety Thermostat is fitted inside the Oven for safety purpose. Incase of the failure of the PID controller the safety thermostat will serve as the temperature controller.

Top panel model with spray injection consist of stainless steel water tank, 2 nos, deluxe motor for dry & spray unit connected to the water bath. Inlet & Outer nozzle is fitted at the side for water supply inside the tank. Outer nozzle is also fitted at the side for cleaning the water tank inside the panel. Specification: As given above having water level to check water inside the tank. Control Panel: Consist of Temp. Controller Le. Thermostat for dry temp. Control, Wet Temp. Controller ER/Thermostat, Mains, Dry. Wet Indicator, Humidity Indicator, Mains, Illumination Switch. Temp. Range Ambient to 40/45°±2° C, Suitable to work on 230 V A.C. Supply. Optional: 1. Digital Controller-cum-Indicator required can be fitted at extra cost Chamber Size (inside) No. of Trays Ltr. 450X450X450 mm 2 95 450x450x700 mm 3 147 605x605x605 mm 2 225 605x605x900 mm 3 335

Specification: Dial Thermometers are useful for measuring the temperature of Soil, Bitumen or any hot material where inserting glass thermometer is risk from breakage point of view. These are essentially bi-metallic thermometers, bimetal element is enclosed in a hollow metallic stem with close fitting. As the temperature rises bimetal element expands and activates a pointer fixed on the dial to read temperature Following sizes are available Dial Sizes: 2” to 6” Stem length: 2” to 48” Material of stem: Stainless steel Ranges: 0-50º C, 0-100º C, 0-150º C, 0-200º C, 0-300º C, 0-400º C -20 to +60º C, -30 to +50º C.
