AZA 1069 EVAPORATING DISHES
Model No. Description
AZA 1069-A Evaporating Dish, Shallow form with
spout, porcelain 100 x 40mm
AZA 1069-B 150 x 45mm
AZA 1069-C 200 x 45mm
Made up of Aluminium / Stainless Steel
Related products
AZA 1054 WATER BATH (6 HOLES)
Specification:
Rectangular water bath double walled construction, inner reservoir of stainless steel. Outer body in mild steel with glass wool insulation in between, supplied with lid having one hole of 12.5cms dia & 6 holes of 7.5 cms dia. Concentric rings with lids are provided on holes. The top plate & concentric rings are of stainless steel temperature range ambient to 100° C.
Controlled by capillary thermostat. Size of the chamber 30cm x 25cm x 12cm.These water baths are useful for laboratory work. Thermometers at extra cost
suitable for: 230 V A.C. Single Phase.
Note: 9 & 12 Holes Water Bath also available
AZA 1058 DIGITAL DOUBLE DOOR DRYING OVEN
This range of ovens is designed for drying large quantities of soil and aggregate samples and maintains temperature in accordance with most B.S. and ASTM requirements. The 225 Lts. and 425 Lts. are economy models constructed with coated mild steel exterior and Stainless Steel coated interior
chamber, which is both durable and corrosion resistant. These units meet the requirements of BS 1377 and are ideal for on-site laboratories and general soil and aggregate testing.
Options And Accessories:
! Dial thermometer with collar fixing for door
! Heavy duty shelves (on Request at an extra price)
! Color of the Oven (Only on qty. greater than 3 Units)
Specifications:
! The larger soil drying ovens are constructed with mild steel and powder coated exterior and Stainless Steel coated chamber which is both durable and corrosion resistant.
! All Sizes of Oven are fitted with a (PID Controller) having a microprocessor digital control as standard.
! All units comes with MCB tripping device in cases of any short circuit, overloading of voltage and Low voltage cut off. Wiring of heaters can be connected / dis-connected removing the side panels of the Oven.
! Caster wheels with locking arrangement are fitted below the Oven for easy movability of the unit from one place to another. Door locking arrangement is very easy & convenient with lever to lock & unlock with half turn lever
! A Safety Thermostat is fitted inside the Oven for safety purpose.
Incase of the failure of the PID controller the safety thermostat will
serve as the temperature controller.
AZA 1061 HEATING MANTLE
Specification:
Most suitable for Labs, Pharmaceuticals, Chemicals Glass
Plants Etc. Useful for heating inflammable liquids electric
heating net is hard Knitted from glass yarn (without any
joint) & for durability &stands temp. Up to 350° C body of
mantle is spun one piece from non rusting Alum (duly stove
1powder coated) mantles are logged with special grade
mineral wool. Most suitable to work on 230 V A.C.
supply. Capacity: From 250 ml to 20 lts
AZA 1062 VACUUM PUMP
High vacuum consist of a metallic casing having Cylindrical bore
accommodating an eccentrically mounted slotted rotor bearing, a
pair of Vanes in the slots forced a part and pressed against the wall
of the casing of the spring. With the rotor these vanes slide along
the wall Casing wiping before them the air which has entered the
apparatus via the suction orifice. The air is finally forced out of the
pump by the Vanes through the oil immersed exhaust valve. The
pumps are made in either single or double stages, the pumps are
electrically operated. Experienced and research in the field, strict
supervision by trained experts and Quality contact by qualified
and experienced engineers. Sizes: 0.25, 0.50, 1.0 HP
available. Operated on 230 V AC, Single Phase Supply, 50 Hz
AZA 1065 HUMIDITY CHAMBER COOLING (SIDE PANEL)
Construction:
Double/Triple walled outer body made of M.S. Sheet duly powder Coated
angle Iron from at bottom with caster wheel for easy moment. Fitted with
Tecumseh / Kirloskar Eco- Friendly Compressor / Condensing Unit for
Uniform& better cooling inside the chamber.
Full size control panel.
Temperature Range: 5 to 50° C
Control Panel:
Consist of Digital Temp, Controller-Cum-Indicator for Dry And Cooling,
Voltmeter, Mains, Wet Temp. Controller, Pilot Lamp for Humidity &
Wet Temperature, Illumination Switch.
HUMIDITY CHAMBER ZI 9021 COOLING (SIDE PANEL)
Chamber Size (inside) No. of Trays L t r .
S. Steel / Aluminium
450 x 450 x 450 mm 2 95
450 x 450 x 700 mm 3 147
605 x 605 x 605 mm 2 225
605 x 605 x 900 mm 3 335
AZA 1067 LABORATORY INCUBATOR
Incubators are designed fabricated & tested to suit various applications in growing field of Medical Agriculture. Research Laboratories of Hospital/Bio-Tech lab. Suitable to work on 230 V A.C. Supply 50 Hz
Construction:
Double walled construction outer body made of M.S. Duly
stovee name l/ powder coated, with inside Aluminium/Stainless Steel Chamber having 60-75mm glass wool insulation, door with glass window for
observation of sample without disturbing. The door is fitted with heavy chrome plated hinge. Provided with adjustable Steel/Aluminium/Wire mesh tray. Temp is recorded means of “L” shaped Prismatic glass Thermometer fitted at the front of the cabinet
Temperature controlled by Hydraulic type Bi-Metallic Capillary Thermostat, having adjustable air ventilators on both sides.
Heating:
Heating element are made from high grade (Kanthal) Resistant wire. Heaters are fitted/wound along all sides & bottom. Complete with 2 pilot lamp cord & plug pin etc
AZA 1070 LABORATORY THERMOMETERS
Specification:
Chemical thermometers made up of high class glass capillary
with prominent mercury or alcohol column as per requirement
for accurate results for Research Laboratories, Institutes,
Schools, Colleges, General laboratories in private sectors.
Range available between -100º C to + 600 º C consumer
should indicate the specified range, least count, accuracy
class. We can also supply according to the customer drawings
& samples
