AZA 1048 FUNNELS AND FLASKS
AZA 1052 STANDS, BOSSHEADS AND CLAMPS
AZA 1053 LABORATORY SCOOPS
AZA 1062 VACUUM PUMP
High vacuum consist of a metallic casing having Cylindrical bore
accommodating an eccentrically mounted slotted rotor bearing, a
pair of Vanes in the slots forced a part and pressed against the wall
of the casing of the spring. With the rotor these vanes slide along
the wall Casing wiping before them the air which has entered the
apparatus via the suction orifice. The air is finally forced out of the
pump by the Vanes through the oil immersed exhaust valve. The
pumps are made in either single or double stages, the pumps are
electrically operated. Experienced and research in the field, strict
supervision by trained experts and Quality contact by qualified
and experienced engineers. Sizes: 0.25, 0.50, 1.0 HP
available. Operated on 230 V AC, Single Phase Supply, 50 Hz
AZA 1065 HUMIDITY CHAMBER COOLING (SIDE PANEL)
Construction:
Double/Triple walled outer body made of M.S. Sheet duly powder Coated
angle Iron from at bottom with caster wheel for easy moment. Fitted with
Tecumseh / Kirloskar Eco- Friendly Compressor / Condensing Unit for
Uniform& better cooling inside the chamber.
Full size control panel.
Temperature Range: 5 to 50° C
Control Panel:
Consist of Digital Temp, Controller-Cum-Indicator for Dry And Cooling,
Voltmeter, Mains, Wet Temp. Controller, Pilot Lamp for Humidity &
Wet Temperature, Illumination Switch.
HUMIDITY CHAMBER ZI 9021 COOLING (SIDE PANEL)
Chamber Size (inside) No. of Trays L t r .
S. Steel / Aluminium
450 x 450 x 450 mm 2 95
450 x 450 x 700 mm 3 147
605 x 605 x 605 mm 2 225
605 x 605 x 900 mm 3 335
AZA 1067 LABORATORY INCUBATOR
Incubators are designed fabricated & tested to suit various applications in growing field of Medical Agriculture. Research Laboratories of Hospital/Bio-Tech lab. Suitable to work on 230 V A.C. Supply 50 Hz
Construction:
Double walled construction outer body made of M.S. Duly
stovee name l/ powder coated, with inside Aluminium/Stainless Steel Chamber having 60-75mm glass wool insulation, door with glass window for
observation of sample without disturbing. The door is fitted with heavy chrome plated hinge. Provided with adjustable Steel/Aluminium/Wire mesh tray. Temp is recorded means of “L” shaped Prismatic glass Thermometer fitted at the front of the cabinet
Temperature controlled by Hydraulic type Bi-Metallic Capillary Thermostat, having adjustable air ventilators on both sides.
Heating:
Heating element are made from high grade (Kanthal) Resistant wire. Heaters are fitted/wound along all sides & bottom. Complete with 2 pilot lamp cord & plug pin etc
AZA 1071 DIAL THERMOMETER
Specification:
Dial Thermometers are useful for measuring the temperature of Soil,
Bitumen or any hot material where inserting glass thermometer is
risk from breakage point of view. These are essentially bi-metallic
thermometers, bimetal element is enclosed in a hollow metallic
stem with close fitting. As the temperature rises bimetal element
expands and activates a pointer fixed on the dial to read
temperature
Following sizes are available
Dial Sizes: 2” to 6”
Stem length: 2” to 48”
Material of stem: Stainless steel
Ranges: 0-50º C, 0-100º C, 0-150º C, 0-200º C,
0-300º C, 0-400º C -20 to +60º C,
-30 to +50º C.
