Cut Section Model of Four Stroke Petrol Engine (AZA 1253)

The A Z A LAB Cut Section Model of a Four Stroke Petrol Engine offers an insightful view of engine components, showcasing the inner workings through a detailed, professionally painted, and dissectible design.

Category: Automobile engineering Lab equipment

Description

The A Z A LAB Cut Section Model of Four Stroke Petrol Engine (Model No: AZA 1253) is an expertly crafted training tool designed for educational purposes. This model features a meticulous cutaway that reveals the internal construction of a four-stroke petrol engine, highlighting essential components such as valves, pistons, pumps, crankshafts, and camshafts. Each part is distinctively colored for easy identification, with many components chromium-plated and galvanized for enhanced durability.

The engine operates manually via a crank handle and is mounted on a sturdy iron frame for stability. It includes a flywheel, and its dissectible design allows for clear demonstrations of engine functionality. A key card and engaging literature are provided to enrich the learning experience.

Features

Operated manually (through a crank handle)
Equipment layout on a sturdy base
Fine finish for aesthetic appeal
Simple operations for ease of use
Functional accuracy for realistic demonstrations

Specifications

Specification	Details
Displacement	160cc
Power	6 hp
Camshaft	In the crankcase
Valves	Overhead
Rpm Regulator	Yes
Oil Pump	Yes
Carburetor	Yes
Air Filter	Yes
Silencer	Yes
Tank	Yes
Dimensions (L x W x H)	500 x 500 x 600 mm
Weight	Approx. 35kg
