Gloss Meter – Triple Angle Models ( AZA 1298 A)
The AZA-GM-T408 Triple Angle Gloss & DOI Meter from AZA Lab is a high-precision instrument engineered for advanced surface analysis. It simultaneously measures gloss, haze, DOI (Distinctness of Image), RIQ (Reflected Image Quality), and gonio photometric profiles, making it ideal for applications requiring comprehensive evaluation of surface appearance and image clarity.
Designed for laboratories, production lines, and quality assurance environments, this meter offers 20°, 60°, and 85° measurement angles, in compliance with international gloss standards. Its rugged aluminum body, large illuminated display, and user-friendly interface ensure long-lasting performance and ease of use—even in demanding conditions.
With Bluetooth® and USB connectivity, integrated memory for up to 999 readings, and support for ElcoMaster™ 2.0 software, the AZA-GM-T408 enables seamless data management and in-depth analysis.
Description
Key Features:
-
Measures gloss, haze, DOI, RIQ, and specular reflectance in one go
-
Triple angle geometry: 20°, 60°, and 85°
-
ISO 17025-traceable calibration with certificate
-
Bright LCD screen with graphs, statistics, and custom display modes
-
Integrated memory for up to 999 readings with time/date stamps
-
Bluetooth® and USB data transfer to ElcoMaster™ software
-
Rechargeable lithium-ion battery: 17+ hrs or 20,000+ readings per charge
-
Fast recharge time: 2.5 hrs (mains) / 4.5 hrs (USB)
-
Onboard trend analysis and multi-language menu system
| Parameter | Range |
|---|---|
| Gloss | 20°: 0–2000 GU, 60°: 0–1000 GU, 85°: 0–150 GU |
| Haze | 0–2000 HU |
| DOI / RIQ | 0–100 |
| Resolution | 0.1 GU / HU / DOI |
| Repeatability | ±0.2 GU / HU / DOI |
| Reproducibility | ±0.5 GU / HU / DOI |
-
ISO 17025 High Gloss Calibration Tile with Certificate
-
Mirror Gloss Calibration Tile
-
Gloss Tile Cleaning Cloth
-
USB Cable
-
Mains Charger (UK, EU, US plug types)
-
ElcoMaster™ 2.0 Software
-
Operating Instructions
Related products
Ball Release for Impact Resistance Tester(AZA 1295)
Applications:
- Used to determine the impact resistance of ceramic floor tiles.
- Suitable for quality assurance in manufacturing, R&D, and certification labs.
- Ensures tile performance in areas exposed to low to moderate mechanical stress.
BALLAST SIEVE – 100 x 70 x 10 cm – 65 mm ( AZA -1299)
The AZA LAB Ballast Sieve Series is designed for the efficient separation, classification, and inspection of railway ballast and coarse aggregates. These sieves are fabricated using heavy-duty steel frames and precision-cut mesh, suitable for demanding environments in both field and laboratory settings.
Each sieve is dimensionally standardized at 100 x 70 x 10 cm, with a custom mesh opening specific to grading needs: 65mm, 40mm, 20mm, and 41.50mm.
These units are ideal for use by railway contractors, quality control labs, construction material testing authorities, and civil engineering departments.
Applications:
- Railway ballast size grading
- Aggregate separation for construction quality control
- Material classification in civil engineering labs
- On-site ballast inspection by railway authorities
DESICCATORS (AZA -1266)
A desiccator is an essential laboratory container used for dry storage and protection of hygroscopic materials from atmospheric moisture. Our desiccators are designed to offer airtight sealing, durability, and resistance to chemical reactions.
Whether you're storing anhydrous chemicals, moisture-sensitive reagents, or conducting vacuum drying, our desiccators are built for consistent, high-performance usage.
FLUX OVEN – 50 KG – STAINLESS STEEL (AZA -1273)
The AZA LAB Flux Oven (50 kg capacity) is a high-performance drying oven designed for precise and uniform heating of flux materials in laboratory and industrial environments. Built with a durable double-walled structure, the oven ensures energy efficiency and thermal stability, making it ideal for demanding applications in ceramics, metallurgy, and materials processing.
With a temperature range of 50°C to 400°C, this oven is equipped with forced air circulation, PID temperature control, and even heat distribution, guaranteeing consistent performance. Safety features include over-temperature protection with an audio alarm, and compatibility with optional data logging systems.
High-precision Thermal Expansion Measurement for Ceramics & Solids (AZA -1269)
| Feature | Specification |
|---|---|
| Heating Element | Special Silicon Carbide (single-end element) |
| Operation Voltage | 5 Amps / 230 V AC |
| Maximum Temperature | 1200 °C |
High-precision Thermal Expansion Measurement for Ceramics & Solids(AZA – 1269 A)
| Feature | Specification |
|---|---|
| Heating Element | High-quality Silicon Carbide element (I Squared R, USA) |
| Operation Power | 15 Amps / 230 V / AC |
| Maximum Temperature | 1400 °C |
| Continuous Operating Temp. | 1400 °C |
Test Specimen Holder for Surface Abrasion Machine – For Glazed Tiles (AZA 1264)
UNIVERSAL GAUGE / PLUCOMETER – WITH DIGITAL GAUGES (AZA-1271 )
The AZA LAB Universal Gauge – Model AZA 1271 is a precision instrument designed for the measurement of surface flatness and warpage in ceramic tiles and related materials. Compliant with BIS 13630 (Part 1), this advanced Plucometer features a digital dial gauge system for highly accurate and user-friendly measurement.
Ideal for use in quality control laboratories and tile manufacturing environments, the system allows direct assessment of surface irregularities across various tile sizes.
