Wood Working Mortiser Tenoning Machine (AZA 1224)

Description

The Wood Working Mortiser Tenoning Machine AZA 1224 by A Z A Lab is a high-performance woodworking machine designed to create precise mortise and tenon joints. Equipped with two electric motors—a 2 hp motor at 2800 rpm and a 1 hp motor at 2800 rpm, both 3-phase—this machine offers exceptional power and versatility. Ideal for professional woodworking shops, the AZA 1224 allows for the creation of accurate square or rectangular mortises and tenons, making it perfect for producing strong joints in furniture and cabinetry.

The AZA 1224 features a robust work table size of 740 x 470 mm (29″ x 18½″), allowing for ample working space. The machine’s table movement of 800 mm (32″) ensures flexibility and convenience when working with different sizes of workpieces. It can accommodate a maximum tenon length of 150 mm (6″) and a maximum workpiece width of 200 mm (8″). For additional precision, it is equipped with two carbide cutter blocks, a miter gauge, and a saw guard, ensuring safe and accurate cuts.

The machine also features a dust collection port with a diameter of 100 mm (4″) to maintain a clean working environment. With its high-quality construction and versatile functionality, the AZA 1224 is an essential tool for any woodworking professional.
