DUST CHIP REMOVER AZA1241
The Dust Chip Remover AZA1241 by AZA LAB is an industrial-grade machine designed for efficient removal of dust, chips, and fine particles from workpieces in woodworking and panel-processing applications. Built for continuous operation, this machine improves surface quality, enhances downstream processing accuracy, and helps maintain a clean and safe production environment.
With a wide 1300 mm working width, high feeding speed, and an advanced combination of mechanical brushing and suction, the AZA1241 is ideal for furniture manufacturing units, panel processing lines, modular furniture factories, and professional woodworking workshops.
Description
Key Benefits
-
Ensures clean, dust-free workpiece surfaces before further processing
-
Reduces manual cleaning time and labor costs
-
Improves finishing quality and machining accuracy
-
Enhances workshop cleanliness and operator safety
-
Suitable for high-volume and continuous production environments
Features
-
Double Nylon Brush System
Effectively loosens and removes surface dust and wood chips without damaging the workpiece. -
High-Efficiency Suction Fan
Instantly extracts dislodged dust particles, preventing re-deposition on the surface. -
Wide Working Width – 1300 mm
Capable of handling large panels and boards with ease. -
High Feeding Speed – Up to 23 m/min
Supports fast and efficient processing for increased productivity. -
Adjustable Working Height (900 ±20 mm)
Allows easy integration into existing production lines and ensures operator convenience. -
Long Conveyor Belt – 5100 mm
Provides smooth, stable, and vibration-free material handling. -
Powerful Multi-Motor Design
Separate motors for feeding, brushing, and dust blowing ensure consistent and reliable performance.
Applications
-
Furniture manufacturing
-
Panel and board processing
-
Modular kitchen and office furniture production
-
Woodworking factories and workshops
-
Pre-finishing and pre-lamination cleaning processes
Technical Specifications
| Specification | Details |
|---|---|
| Model | AZA1241 |
| Make | AZA LAB |
| Working Width | 1300 mm |
| Workpiece Thickness | 30 – 50 mm |
| Minimum Workpiece Length | 350 mm |
| Feeding Speed | Up to 23 m/min |
| Working Height | 900 ±20 mm |
| Conveyor Belt Length | 5100 mm |
| Blow Dust Motor | 0.25 kW × 4 |
| Feeding Motor | 1.5 kW |
| Brush Motor | 1.5 kW |
| Total Installed Power | 4 kW |
Why Choose AZA LAB?
AZA LAB machines are engineered for durability, efficiency, and consistent performance. The Dust Chip Remover AZA1241 combines intelligent design with reliable components to deliver long-term value and superior cleaning results for professional woodworking operations.
