WET SIEVE SHAKER AZA0927 - Image 1
Click to enlarge
SIEVE SHAKER ‘GYRATORY’ AZA0926
SIEVE SHAKER ‘GYRATORY’ AZA0926
Back to products
sieve brushes, lab cleaning, mesh cleaning
SIEVE BRUSHES AZA0928

WET SIEVE SHAKER AZA0927

The Azalab AZA0927 Wet Sieve Shaker is a robust laboratory instrument engineered for the accurate determination of particle size distribution in fine-grained soils, aggregates, and other materials where dry sieving is ineffective. By combining controlled mechanical agitation with a continuous water spray, the AZA0927 ensures complete disintegration of agglomerates and reliable separation of fine particles.

Wet sieving using the AZA0927 is essential for materials containing silt, clay, dust, or cohesive fines, where dry methods tend to underestimate the fine fraction due to particle adhesion or electrostatic effects. The instrument is widely used in geotechnical, civil, environmental, mining, ceramics, and material testing laboratories

View Specification PDF
Enquiry on WhatsApp
Category:
Description

Description

Principle of Operation

The AZA0927 integrates mechanical shaking with hydraulic washing to achieve accurate particle separation:

  1. A prepared sample is placed on a stack of standard test sieves arranged in descending mesh size.

  2. The sieve stack is secured inside the wet sieve shaker.

  3. Water is uniformly sprayed over the top sieve while the machine imparts a controlled shaking motion.

  4. Fine particles are washed through the sieve apertures, preventing clogging and agglomeration.

  5. Material retained on each sieve is collected, dried, and weighed for particle size analysis.

This method ensures that each particle is fully exposed to the sieve openings, resulting in accurate, repeatable, and representative gradation results.

Key Features and Advantages

  • Designed specifically for wet sieving applications

  • Efficient removal of fines adhering to coarse particles

  • Corrosion-resistant construction suitable for continuous water exposure

  • Uniform and controlled shaking motion for consistent results

  • Integrated water spray system for effective washing

  • Accommodates standard 200 mm (8″) test sieves

  • Secure clamping system for stable sieve stacking

  • Optional digital timer with auto shut-off

  • Effective drainage system for clean laboratory operation

  • Low maintenance and long service life

Applications

  • Grain size analysis of soils (sand, silt, clay fractions)

  • Aggregate washing and gradation testing

  • Sediment and sludge analysis

  • Mining ores, fines, and tailings characterization

  • Ceramic raw material preparation

  • Powdered and fine industrial materials

Standards Compliance

The AZA0927 is designed to support testing in accordance with:

  • IS 2720 (Part 4) – Grain Size Analysis of Soils (Wet Sieving)

  • ASTM D6913 – Particle-Size Distribution of Soils

  • ASTM C117 – Materials Finer than 75 µm (No. 200) Sieve by Washing

  • Relevant ISO standards for particle size analysis

Technical Specifications

Parameter Description
Model AZA0927
Product Type Wet Sieve Shaker
Sieve Diameter Compatibility 200 mm (8″)
Sieve Capacity 6–8 sieves + lid & receiver pan
Shaking Motion Rotary & tapping / orbital (model dependent)
Motor Heavy-duty electric motor
Power Supply 230 V AC, 50 Hz, Single Phase
Timer Digital timer with auto shut-off (optional)
Water Supply Continuous inlet connection
Drainage Integrated tray with outlet hose
Construction Corrosion-resistant materials
Safety Features Splash guard / enclosed wet area
Operation Wet sieving only
Standards IS, ASTM, ISO compliant
Country of Origin Made in India

Frequently Asked Questions (FAQ)

Q1. When is wet sieving required instead of dry sieving?
Wet sieving is required for cohesive soils and materials containing fine particles that clump together, where dry sieving produces inaccurate results.

Q2. What sieve sizes are supported?
The AZA0927 is compatible with standard 200 mm (8″) diameter test sieves.

Q3. Is water supply mandatory?
Yes. Continuous water supply and proper drainage are essential for operation.

Q4. Does the unit include a timer?
A digital timer with auto shut-off is available, depending on configuration.

Q5. Which standards does the AZA0927 comply with?
IS 2720 (Part 4), ASTM D6913, ASTM C117, and relevant ISO standards.

Additional information

Additional information

Model

AZA 0927
Product Type

Wet Sieve Shaker
Sieve Diameter Compatibility

Standard 200 mm (8-inch) diameter test sieves.
Dimensions (Approx.)

[H x W x D, e.g., 800 x 400 x 500 mm].
Weight (Approx.)

[e.g., 30-50 kg]
Country of Origin

Made in India
Safety Features

Splash guard/enclosure for safe operation.
