HEAVY DUTY BALANCE AZA1089
The AZA1089 Heavy Duty Balance is a high-capacity digital industrial weighing scale engineered for laboratories and production environments that require accurate weighing of large, bulky, or heavy materials. Designed for durability, stability, and precision, this balance is widely used in quality control labs, manufacturing plants, R&D facilities, cement and concrete labs, agriculture, and material testing environments.
Built to handle demanding workloads, the AZA1089 combines a robust mechanical structure with reliable electronic measurement, delivering consistent and repeatable results even under high-load conditions.
Description
The AZA1089 supports weighing capacities ranging from 10 kg up to 100 kg, depending on the model configuration. Multiple readability options — 0.1 g, 1 g, or 10 g — allow users to select the ideal balance for their specific application, whether measuring bulk powders, filled containers, fabricated components, or raw materials.
A large stainless steel weighing platform accommodates oversized samples, while the reinforced base frame minimizes vibration and ensures excellent stability during operation. The bright LCD or LED digital display offers clear visibility in laboratory, warehouse, or industrial settings.
Design & Construction
- Stainless Steel Platform: Corrosion-resistant and easy to clean
- Heavy-Duty Frame: Ensures stability under high loads
- Reinforced Housing: ABS plastic or coated metal for long-term durability
- Adjustable Feet & Level Bubble: Accurate leveling on uneven surfaces
- Sealed Membrane Keypad: Resistant to dust, moisture, and spills
Optional battery operation allows portability for field or warehouse applications where fixed power supply may not be available.
Functional Features
The AZA1089 includes a comprehensive set of weighing functions:
- Tare and zero tracking
- Multiple unit conversion (g, kg, lb, ct, pcs)
- Piece counting for inventory and packing operations
- Overload warning and protection
- Low-battery indicator
- Auto or external calibration (model dependent)
For regulated environments, the balance can be supplied with traceable calibration certificates in accordance with ISO/IEC 17025 and GLP requirements.
Typical Applications
AZA1089 is ideal for:
- Cement, concrete, and construction material testing
- Metallurgical and mechanical component weighing
- Chemical and pharmaceutical bulk material handling
- Agricultural produce and fertilizer measurement
- Food processing and packaging weight verification
- R&D formulation and batch preparation
- Warehouse and incoming material inspection
Optional RS-232 or USB interfaces enable integration with computers, printers, or Laboratory Information Management Systems (LIMS).
Safety & Reliability
- Built-in overload protection to prevent sensor damage
- Non-slip rubber pads for secure bench placement
- Wide operating temperature tolerance for industrial use
- Stable readings even under dynamic loading conditions
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | AZA1089 |
| Capacity Range | 10 kg – 100 kg (model dependent) |
| Readability | 0.1 g / 1 g / 10 g |
| Platform Size | 250 × 250 mm to 500 × 500 mm |
| Display | LCD / LED, backlit |
| Calibration | External or Auto (based on model) |
| Platform Material | Stainless steel |
| Housing Material | Reinforced ABS / coated metal |
| Power Supply | AC adapter / Rechargeable battery |
| Weighing Units | g, kg, lb, ct, pcs |
| Interface | RS-232 / USB (optional) |
| Compliance | ISO/IEC 17025, GLP-ready |
| Operating Temperature | 10°C – 45°C |
| Overload Protection | Yes |
Frequently Asked Questions (FAQ)
Q1: What is a heavy duty balance used for?
It is used for weighing large or heavy samples in industrial laboratories, quality control, manufacturing, and material testing environments.
Q2: How accurate is the AZA1089?
Accuracy depends on the model, with readability ranging from 0.1 g to 10 g across different capacity variants.
Q3: Can this balance be used in semi-outdoor or workshop areas?
Yes. Its rugged construction and wide operating temperature range make it suitable for warehouses, workshops, and semi-outdoor labs.
Q4: Does it support computer or printer connectivity?
Yes. Optional RS-232 or USB ports allow integration with PCs, printers, or LIMS systems.
Q5: Is calibration certification available?
Yes. The balance can be supplied with traceable calibration certificates as per ISO/IEC 17025 upon request.
Product Highlights
- High-capacity electronic balance for heavy samples
- Stainless steel platform with robust industrial design
- Capacity up to 100 kg with selectable precision
- Tare, unit conversion, piece counting, overload protection
- Suitable for industrial labs, QC, R&D, and field testing
Model: AZA1089
Additional information
| Capacity |
10 kg to 100 kg (model dependent) |
|---|---|
| Readability |
0.1 g / 1 g / 10 g |
| Platform Size |
250 mm – 500 mm (L×W) |
| Display |
LCD / LED (backlit) |
