Aniline Point Tester AZA1328
The Aniline Point Tester (Model: AZA1328) from AZA Lab is a precision instrument designed for determining the aniline point and mixed aniline point of petroleum products and hydrocarbon solvents, in accordance with ASTM D611 Standard Test Methods. The aniline point is a critical parameter indicating the aromatic content and solvency properties of fuels and hydrocarbons. This instrument is widely used in laboratories, refineries, fuel quality control centers, and research facilities to ensure accurate characterization of product composition, compatibility, and performance.
The AZA1328 provides fully automated operation with integrated safety features, ensuring precise, reliable, and reproducible results while minimizing operator intervention.
Description
Key Applications & Features
-
High-Precision Measurement: Accurately determines the temperature at which aniline and the test sample are completely miscible, critical for evaluating aromatic content.
-
Mixed Aniline Point Testing: Can measure samples with aniline points below the crystallization temperature, providing enhanced analytical flexibility.
-
7-inch Color LCD Touch Screen: Modern, user-friendly interface displaying real-time data and operational status.
-
Imported Photoelectric Sensors: Ensures high repeatability and accuracy in detecting the miscibility endpoint.
-
Automatic One-Key Operation: Complete test cycle from heating, stirring, and detection to recording and printing is fully automated.
-
Over-Temperature Alarm: Stops the test and alerts the user if the sample temperature exceeds 170°C, enhancing safety.
-
Microprocessor-Controlled System: Handles heating, stirring, detection, data storage, printing, and shutdown for efficient workflow.
-
Data Management: Stores up to 200 records, allowing for historical data tracking and reporting.
-
Printing Capability: Built-in micro printer provides hard copies of test results for documentation and compliance.
-
Compact, Durable Design: Stainless steel body and high-quality components ensure long-term stability and minimal maintenance.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | AZA1328 |
| Temperature Control Range | Room temperature ~ 170°C |
| Temperature Accuracy | ±0.1°C |
| Heating Method | Electric heating rod |
| Heating Power | 60 W |
| Stirring Method | Motor-driven soft shaft |
| Detection Method | Photoelectric sensor |
| Storage Capacity | 200 records |
| Printing Method | Micro printer |
| Power Supply | AC 220 V ±10%, 50 Hz |
| Optional Accessories | Stainless steel tray: 1 Glass test tube: 1 |
Applications in Industry
-
Fuel and Lubricant Quality Control: Evaluates aromatic content and compatibility.
-
Refineries: Assesses feedstock characteristics and process suitability.
-
Laboratories & Research: Supports analysis of hydrocarbon solvent properties and product formulation.
-
Regulatory Compliance: Ensures conformity with ASTM D611 and other industry standards.
The AZA1328 Aniline Point Tester is a highly reliable, fully automated, and user-friendly instrument that combines precision, safety, and efficiency, making it an essential tool for laboratories and industrial quality control operations.
