AZA LAB 112 welding Machine
Description
Suitable to cut/drill cores of concrete, rocks, stones, tiles or the similar
materials. The machine is suitable for core samples of size upto 150 mm
diameter with the help of thin walled diamond bits which are at extra cost.
The machine has sturdy base with pillar support in which rack and pinion is
provided for adjustment in height and penetration assembly. The leveling
screws are provided at the base. For gripping the sample in position
suitable grips are provided. A suitable petrol engine is fitted in the machine
with cooling arrangement with water. The base frame is also fitted with
wheels for ease of transportation.
Dimension approx, are as under:
Height : 1300 mm
Base : 625 x 900 mm
Head travel on rack : 500mm
Drill speeds : 900 R.P.M. for soft samples and 350 R.P.M. for hard Samples
Water swivel : Built in the machines.
Accessories : (1) Thin wall diamond bits.
(2) Core barrel.
(3) Petrol engine 190 cc
Additional information
| Model |
AZALAB 112A ,AZALAB 112B |
|---|
Related products
DEVEL ATTRITION TESTER AZA0989
Key Applications
- Road and highway material testing
- Railway ballast quality assessment
- Concrete mix design durability testing
- Civil engineering research & academic laboratories
FLAKINESS SIEVE SET AZA0973
The AZA0973 Flakiness Sieve Set is a laboratory-grade testing instrument designed to determine the flakiness index of coarse aggregates. It is an essential tool for evaluating aggregate particle shape, helping ensure strength, durability, and performance of concrete and road construction materials. This system is manufactured for full compliance with IS 2386 (Part I) and is widely used in civil engineering laboratories and construction quality control sites.
Key Features
-
Used for determining flakiness index of coarse aggregates
-
Fully compliant with IS 2386 (Part I) standards
-
Precision-machined slotted gauges for multiple aggregate sizes
-
Heavy-duty stainless steel / powder-coated steel construction
-
Corrosion-resistant, long service life
-
Portable and easy to use in lab and field environments
GRID SIEVES AZA0972
The AZA0972 Grid Sieves are heavy-duty screening tools designed for rapid particle size classification of coarse soils and aggregates. These sieves are ideal for quick, visual separation of gravel, crushed stone, and coarse sands in civil engineering, geotechnical, and construction materials laboratories. Their rugged construction makes them suitable for both laboratory and field applications.
Key Features
-
Designed for fast classification of coarse particles
-
Suitable for soil and aggregate testing
-
Heavy-duty stainless steel / galvanized steel construction
-
Precision-welded square or rectangular grid openings
-
Corrosion-resistant, abrasion-resistant long life design
-
Compatible with standard manual and mechanical sieve shakers
INDEX APPARATUS (FLOW COEFFICIENT OF FINE AGGREGATES) AZA0975
The AZA0975 Flow Coefficient Index Apparatus is a precision laboratory instrument designed to measure the flow coefficient of fine aggregates, such as natural sand and crushed sand. This test helps evaluate workability, particle shape, and grading, which are critical factors in concrete and mortar mix performance. The apparatus is manufactured in compliance with IS 2386 (Part I) and is widely used in civil engineering laboratories and construction quality control departments.
Key Features
-
Measures flow coefficient of fine aggregates
-
Fully compliant with IS 2386 (Part I)
-
Evaluates workability and particle shape characteristics
-
Supplied as a complete set: funnel, stand, cylinder, and base plate
-
Precision-machined components for consistent results
-
Corrosion-resistant, durable construction
-
Easy manual operation for laboratory and field use
LENGTH GAUGE AZA0971
The AZA0971 Length Gauge is a precision construction materials testing instrument designed to determine the elongation index of coarse aggregates. It is an essential tool for evaluating particle shape characteristics, which directly influence the strength, durability, and workability of concrete and asphalt mixes. The gauge is manufactured to strict quality standards, ensuring reliable and repeatable results in laboratory and field environments.
Key Features
-
Designed for determining elongated particles in coarse aggregates
-
Essential for concrete, bituminous, and road material analysis
-
Precision metal frame with standard machined slot dimensions
-
Heavy-duty, corrosion-resistant construction
-
Accurate performance as per international and national standards
RIFFLE SAMPLE DIVIDER AZA0980
Key Features
- Accurate material splitting for laboratory testing
- Heavy-duty corrosion-resistant metal construction
- Uniform slot widths for consistent sample division
- Smooth-flow chute design for minimal sample loss
- Supplied with two receiving pans for clean, efficient operation
- Compact bench-top design
SAMPLE SPLITTER AZA0981
Key Features
- Accurately splits bulk aggregates into representative samples
- Multiple slot options for different particle sizes
- Heavy-duty powder-coated steel frame
- Uniform chute spacing for even material distribution
- Supplied with two sturdy collection pans
- Portable and easy to operate
SHAPE INDEX CALIPER AZA0974
The AZA0974 Shape Index Caliper is a precision hand-held measuring instrument designed to evaluate the shape index of coarse aggregates by measuring their flakiness and elongation values. It is an essential tool in construction material testing, helping laboratories and site engineers ensure that aggregates meet dimensional and performance standards as per IS 2386 (Part I).
Key Features
-
Evaluates shape index of coarse aggregates
-
Measures both flakiness and elongation characteristics
-
Durable stainless steel / hardened steel construction
-
Precision engraved measuring scale
-
Ergonomic, easy-to-handle manual design
-
Suitable for laboratory and on-site field use
-
Fully compliant with IS 2386 (Part I)
