Showing 121–132 of 459 results
AZA 0924 BRASS FRAME SIEVES 100,200, 300 & 450 MM DIA.
(BS 410) (IS 460 part 1.1985) ASTM E 11 micron (Aperture)
- 4.75 micron 4 4750
4 4.00 micron 5 4000
5 3.35 micron 6 3350
6 2.80 micron 7 2800
7 2.36 micron 8 2400
8 2.00 mm 10 2000
10 1.70 mm 12 1680
12 1.40 mm 14 1400
14 1.18 mm 16 1200
16 1.00 mm 18 1000
18 850 micron 20 850
22 710 micron 25 710
25 600 micron 30 600
30 500 micron 35 500
36 425 micron 40 425
44 355 micron 45 355
52 300 micron 50 300
60 250 micron 60 250
72 212 micron 70 210
85 180 micron 80 180
100 150 micron 100 150
120 125 micron 120 125
150 106 micron 140 106
170 90 micron 170 90
200 75 micron 200 75
240 63 micron 230 63
300 53 micron 270 53
350 45 micron 325 45
400 38 micron 400 38
500 25 micron - 25
AZA 0925 SIEVE SHAKER ‘ROTAP’
Specification:
To make process of sieving simpler and quicker, Rotap sieve shaker is useful , this produces circular shaking of the sieves. At the same time the sieves are tapped. The mechanism for imparting circular action and topping is oil immersed in a tank and in motorized. The shaker can accommodate upto 7 nos. Sieves of dia 150mm or 200mm. Suitable operation of 230 V A.C. Single
Phase.
AZA 0926 SIEVE SHAKER ‘GYRATORY’
Specification:
Carries upto 7 sieves of 150 or 200 mm diameter. The shaker is driven by a 1/4 H.P. Motor through a reduction gear immersed in oil. The sieve table does not rotate but is inclined from the vertical axis and the direction on inclination charges progressively in clockwise direction. If the stop pin below the table is removed, the shaker can have a rotary motion. In addition to this gyratory motion of the table, there is an upward and downward movement ensuring that each square cm of the sieve is utilized. A pair of rods and a holder can be fixed on the top of the upper most sieve, and thus the sieve set in firmly
held. Suitable for operation from 230 V 50 Hz, Single phase A.C. supply.
a) Adopter for 300 mm dia. sieve available at extra cost
b) Adopter for 450 mm dia. sieve available at extra cost
AZA 0927 WET SIEVE SHAKER
This is yodar type, motor driven sieve shaker for carrying out wet sieve analysis of materials.
Specification:
Consists of a water reservoir and a holder for sieves, which can take up to 7 sieves of 150mm or 200mm diameter. Shaker is driven by a ¼ H.P. motor through a belt drive. Shaker mechanism moves the sieves up and down in the reservoir. The reservoir has a water out-let for draining out the used water. Suitable for operation 230 V A.C. Single Phase
AZA 0928 SIEVE BRUSHES
AZA 0929 PLATE BEARING TEST
IS 1888 1962, ASTM D 1194, BS 13779
This is for estimating the bearing capacity of shallow foundations in situ and for the design of flexible pavement. In the test procedure a steel plate is subjected to gradually increasing load and settlements of the plates
recorded.
Specification: The out fit consists of 50 tonne hydraulic jack with separate pumping unit fixed to it a 0 - 500KN x 0.5KN. 1No. Pressure gauge and flexible metal pipe 5 mtr. long 1No. Special ball and socket arrangement between the jack and the bearing plate 1 No. Extension rod 12mm dia x 25 cm long
for taking dial gauge readings 16 Nos. Magnetic base with female thread on top for holding extension rod 4 Nos. Top end plate, 50mm, dia with male
thread for fitting onto the extension rods and positioning the dial gauge plunger 4 Nos. Column 15cm dia x 25cm long with flanges complete with four bolts and nuts 2 Nos. Column 15cm dia x 50cm long with flanges complete with four bolts and nuts 1 No. Bridge support of welded steel angle construction, 5 mtr. Span and stands approximately 30 cm. High. Fitted with two quick release clamps a for positioning and holding the dial bracket 2 Nos.
Accessories:
Plane M.S. 75mm x 25mm thick
Plane M.S. 50cm x 25mm thick
Grooved M.S. plate 60cms x 60cms x 25mm thick
Grooved M.S. plate 45cms x 45cms x 25mm thick
Grooved M.S. plate 30cms x 30cms x 25mm thick
Grooved M.S. plate 75cms x 75cms x 25mm thick
AZA 0930 LIGHT WEIGHT DEFLECTOMETER
ASTM E2835-11
Corresponding to “German technical test code for soil and rock mechanics in road constructions” TP BF-STP part B 8.3 from the German federal road research institute ( Bu ndesan stal t f ü r straß enwesen ) accredited compaction test according to ZTV E 2009 and ZTV A 2012 (German supplementary technical terms and conditions of contract and guidelines for earthworks in road construction and excavations in traffic areas) RIL 836 German National Railway Company Deutsche Bahn AG Calibration record corresponding to German standard
TP BF-STB part B 8.3 Detailed instruction manual in English ASTM E2835-11
Corresponding to “German technical test code for soil and rock mechanics in road constructions” TP BF-STP part B 8.3 from the German federal road research institute ( Bu ndesan stal t f ü r straß enwesen ) accredited compaction test according to ZTV E 2009 and ZTV A 2012 (German supplementary technical terms and conditions of contract and guidelines for earthworks in road construction and excavations in traffic areas) RIL 836 German National Railway Company Deutsche Bahn AG Calibration record corresponding to German standard
TP BF-STB part B 8.3 Detailed instruction manual in English
Software in English:
Software for MS-Windows NT, windows 2000, XP, vista, windows 7 on cd rom presentation of testing points with date and time in satellite picture (can be turned off) Individual data records with user-designed company logo and color coded settlement curves as A4 sized record.
AZA 0931 INTEGRAL PROVING RINGS
The Proving rings are made of special steel carefully forged to give maximum strength and machined to give high sensitivity commensurate with stability ensuring long life and accuracy. All proving rings are integral type viz, the loading (outside) bosses are forged integral with the ring body.
This ensures that there is no possibility of abutment shift and consequent loss of accuracy in reading that always exists with bolted abutments. The dial gauge and anvil are mounted on U-brackets clamped to the ring body by set screw. The dial gauge is fitted with a special back cover and threaded bush.
Which does not permit any shift from the original dial alignment, coaxial with the loading boss centres, that is set at the factory before calibration. For all compression proving rings and tension compression proving rings up to and including 5 KN capacity the loading bosses have female threading ½” BSP (16 TPI)
The boss faces are ground and polished and are plane parallel to within 0.2mm total DTI run out. Tension compression rings have their integral loading bosses male threaded, 1.25” dia, 8 tpi square thread, 1.25” long. Caps are provided for use when loading in compression Repeatability is as stipulated in IS 4169 The rings are supplied complete with dial gauge and Works
calibration Chart. Individually packed in polished wooden. Boxes. NCCBM Calibration can also be arranged for any proving ring at an additional cost.
Proving rings to meet special requirements are also available on request.
Separate polished and ground pair of Loading Pads FOR Compression Proving Rings and Pair of Shackles for Tension Proving Rings are provided to suit each proving ring, at extra cost.
AZA 0932 RING AND BALL APPARATUS
IS 1205 1985, IP 58/63 & ASTM D 36
This apparatus is used to determine Softening point of Bitumen. It is that temperature at which a sample of bituminous material loaded by a 9.5mm dia steel ball, drops a specified distance when heated under specified conditions.
Specification:
The apparatus consists of steel bracket with a sliding plate support. That support has two holes of 10mm dia on which a ring and ball guide can be kept. A central hole on this plate is for inserting thermometer. Supplied with a glass beaker approximate 600ml, high and a hand stirrer and 2 Nos. 9.5mm dia steel balls
AZA 0933 RING AND BALL APPARATUS (ELECTRICAL)
ASTM D36, AASHTO T 53, BS 2000Electrical heating, with a Heater and Energy Regulator, Suitable for operation on 230 V, 50Hz, Single Phase, A.C. supply. Each unit is supplied with bath of heat resistant glass and the following.
AZA 0933-A Tapered Rings 2 Nos.
AZA 0933-B Ball Centering Guide 2 Nos.
AZA 0933-C Steel Ball, of 9.5mm dia. 2 Nos.
AZA 0933-D Ring Holder 1 No.
AZA 0933-E Electric Heater (Hot Plate) 1 No.
Essential Accessories:
AZA 0933-F Thermometer IP 60° C, Range : -2° C to 80° C
AZA 0933-G Range: 30° C to 200°C
AZA 0934 RING & BALL APPARATUS(SEMI AUTOMATIC)
Ref. Standards - IS:1205, ASTM D 36, E 28, IP 198, IP 58,
AASHTO T53, BS:2000, EN 1427
For determining the temperature at which a sample of bituminous material loaded by a 9.5 mm dia steel ball, drops a specified distance when heated under specified conditions.
Ring and Ball Apparatus
The new design of Ring and Ball Apparatus is compact user friendly and has better aesthetics. It has magnetic stirrer with heating facility and digital display of temperature, the heating can be adjusted through knob.
Suitable for operation on 220 V, 50 Hz, single phase, AC supply. Each unit is supplied with a bath of heat resistant glass and the following:
AZA 0934-A Tapered Rings 2 Nos.
AZA 0934-B Ball Centering Guide 2 Nos.
AZA 0934-C Steel Balls of 9.5 mm dia 2 Nos.
AZA 0934-D Ring Holder 1 No.
AZA 0934-E Electric Heater (Hot Plate) 1 Nos
AZA 0935 FRAASS BREAKING POINT APPARATUS
En 12593
AZA 0935 Fraass Breaking Point Apparatus
AZA 0935-A Stainless Steel Plaque
AZA 0935-B Frass Apparatus (pack of 10)
Dry ice maker
The AZA 0935 Breaking Point Apparatus is used to determine the breaking
point of solid and semisolid bitumen. The Fraass Breaking Point is the temperature at which bitumen first becomes brittle, as indicated by the appearance of cracks when a thinfilm of the bitumen on a metal plaque is cooled and flexed in accordance with specified conditions. The apparatus consists of stainless steel plaque, cooling and bending
apparatus, thermometer IP 42C (-38°C/+30°C), plate and stand
