GROUT SAMPLE BOX AZA1161
The Grout Sample Box from Azalab is a practical, cost-efficient solution for preparing grout prisms in accordance with industry-recognized standards. Engineered for reliability and ease of use, it serves as a superior alternative to traditional steel prism molds, offering faster preparation and consistent specimen quality in both field and laboratory conditions.
Designed to fully comply with ASTM C-1019 and UBC 21-18, the sample box enables technicians to produce grout samples that accurately replicate the moisture absorption behavior of CMU units. Its engineered slotted corrugated construction promotes appropriate water retention, supporting uniform curing and improving the validity of compressive strength test results.
Each box forms four grout specimens, precisely sized at 6.25 mm × 81.5 mm × 162.5 mm, eliminating the need for bulky molds or time-consuming cleaning. Lightweight, disposable, and stackable, these boxes streamline the entire sampling process, especially in high-volume QA/QC programs.
Description
Specifications
| Feature | Details |
|---|---|
| Model | AZA1161 |
| Standards Compliance | ASTM C-1019, UBC 21-18 |
| Material | Engineered slotted corrugated cardboard |
| Specimen Size | 6.25 mm × 81.5 mm × 162.5 mm |
| Specimens per Box | 4 |
| Moisture Retention | Yes – simulates CMU absorption |
| Shipping Unit | 25 boxes per carton |
| Design | Lightweight, stackable, disposable |
| Applications | Grout prism sampling, construction QA/QC, laboratory testing |
Frequently Asked Questions (FAQ)
Q1: Does this box meet ASTM and UBC requirements?
A1: Yes. It complies fully with ASTM C-1019 and UBC 21-18 for grout strength testing.
Q2: How many specimens can be cast in one box?
A2: Each box produces four grout specimens of standard test size.
Q3: Is the box reusable?
A3: No. It is a single-use, disposable product designed to reduce labor and eliminate cleanup.
Q4: How does the design help with moisture retention?
A4: The slotted corrugated structure replicates CMU absorption characteristics, retaining moisture to support proper curing.
Q5: How are the boxes packaged for shipping?
A5: Each carton contains 25 grout sample boxes, making them suitable for high-volume testing operations.
