GLOSS METER – TRIPLE ANGLE MODELS AZA1298A
The AZA1298A Triple Angle Gloss Meter from AZA LAB is a high-precision surface gloss measurement instrument designed for professional quality control, laboratory testing, production inspection, and standards-compliant surface evaluation.
The instrument measures gloss simultaneously at the three internationally recognized geometries:
- 20°
- 60°
- 85°
allowing accurate assessment of high-gloss, semi-gloss, satin, and matte surfaces using a single compact handheld device.
Engineered for industrial, laboratory, and field applications, the AZA1298A delivers highly repeatable and reliable gloss measurements in Gloss Units (GU) while supporting haze and DOI (Distinctness of Image) analysis for advanced surface characterization.
Its advanced optical system, integrated data storage, USB connectivity, and ergonomic portable design make it ideal for paints, coatings, automotive, plastics, furniture, packaging, ceramics, flooring, and industrial finishing industries.
Description
STANDARDS COMPLIANCE
The AZA1298A fully complies with internationally recognized gloss measurement standards:
- ASTM D523
- ISO 2813
- GB/T 9754
This ensures suitability for:
- International audits
- OEM approvals
- Export manufacturing
- Regulatory quality verification
WHY TRIPLE ANGLE MEASUREMENT MATTERS
Surface appearance changes significantly depending on gloss level and viewing geometry.
The AZA1298A integrates all three standard gloss measurement angles into one instrument for complete surface analysis.
20° GEOMETRY
Ideal for:
- High-gloss automotive coatings
- Polished surfaces
- Lacquer finishes
- Mirror-like materials
60° GEOMETRY
General-purpose measurement for:
- Industrial coatings
- Semi-gloss finishes
- Standard paint applications
- General QC testing
85° GEOMETRY
Designed for:
- Matte finishes
- Low-gloss coatings
- Textured surfaces
- Interior decorative paints
This eliminates the need for multiple gloss meters and allows direct comparison across different material finishes.
TECHNICAL SPECIFICATIONS
| PARAMETER | SPECIFICATION |
|---|---|
| Model | AZA1298A |
| Product Type | Triple Angle Gloss Meter |
| Measuring Angles | 20°, 60°, 85° |
| Gloss Range (20°) | 0–2000 GU |
| Gloss Range (60°) | 0–1000 GU |
| Gloss Range (85°) | 0–150 GU |
| Haze Range | 0–2000 HU |
| DOI / RIQ Range | 0–100 |
| Resolution | 0.1 GU / HU / DOI |
| Repeatability | ±0.2 GU / HU / DOI |
| Reproducibility | ±0.5 GU / HU / DOI |
| Display | LCD with Backlight |
| Calibration | Manual & Automatic |
| Interface | USB |
| Battery Life | Up to 12 Hours Continuous Use |
| Dimensions | Approx. 160 × 50 × 80 mm |
| Weight | Approx. 350 g |
| Standards Compliance | ASTM D523, ISO 2813, GB/T 9754 |
INCLUDED ACCESSORIES
- AZA1298A Triple Angle Gloss Meter
- ISO 17025 High-Gloss Calibration Tile with Certificate
- Mirror Gloss Calibration Tile
- Gloss Tile Cleaning Cloth
- USB Cable
- Mains Charger (UK / EU / US Plug Types)
- ElcoMaster™ 2.0 Software
- Operating Instructions
- Protective Carrying Case
OPTIONAL ACCESSORIES
- Additional calibration standards
- Extended software package
- Spare rechargeable battery
- Surface cleaning kit
- Portable field stand
- Calibration verification tiles
ADVANTAGES
- Complete multi-angle gloss analysis
- Compact and portable design
- Fast and highly accurate measurements
- Excellent repeatability
- Suitable for laboratory and field applications
- Advanced haze and DOI analysis
- Built-in memory and USB reporting
- International standards compliance
- Durable industrial construction
- Long battery operating life
COMPLIANCE & APPLICABILITY
The AZA1298A is designed for professional gloss, haze, and surface appearance measurement according to ASTM, ISO, and GB/T standards.
The instrument is suitable for industrial quality control, product certification, surface inspection, research laboratories, OEM manufacturing, and advanced coating analysis applications.
Additional information
| Measuring Angles |
20°, 60°, 85° |
|---|---|
| Measuring Range |
0–1000 Gloss Units (GU) |
| Resolution |
0.1 GU |
| Accuracy |
±1.0 GU (standard white tile) |
