PLASTIC MOULDS AZA1125
The AZA1125 One-Piece Plastic Cube Mould (150 mm) from Azalab is a next-generation alternative to traditional metal cube moulds. Built from high-strength, non-deformable engineering plastic, this mould is designed to offer superior ease of use, long service life, and consistent dimensional accuracy for concrete compressive strength testing.
Its seamless, single-piece construction eliminates the need for bolts, screws, or external frames. Users simply apply demoulding oil, cast the concrete, and after curing, eject the cube using compressed air or water pressure, achieving clean and damage-free removal every time.
Compared to heavy metal moulds, the AZA1125 weighs nearly 90% less, providing clear advantages in portability, handling, and storage—making it ideal for both laboratory and on-site testing environments. Manufactured using an eco-friendly, non-polluting process, this mould supports sustainability goals in modern construction testing.
Description
Key Features
-
One-piece mould design – no bolts, screws, or assembly required
-
High-strength engineering plastic – durable, lightweight, and deformation-resistant
-
Fast demoulding – cube is expelled using compressed air or water pressure
-
Reusable – withstands multiple test cycles with simple cleaning and re-oiling
-
Non-corrosive & non-stick – maintains smooth internal finish over time
-
Eco-friendly production – non-polluting and recyclable plastic
-
Ultra-lightweight – approx. 1/10th the weight of metal moulds
-
Standards compliant – IS 516, ASTM C109, BS EN 12390
Specifications
| Feature | Details |
|---|---|
| Model No. | AZA1125 |
| Product Name | One-Piece Plastic Cube Mould |
| Cube Size | 150 mm (standard concrete cube) |
| Construction | Precision-moulded hard plastic (single piece) |
| Demoulding Method | Compressed air or water pressure |
| Reusability | Yes – suitable for multiple test cycles |
| Cleaning | Simple washing + demould oiling before each use |
| Standards Compliance | IS 516, ASTM C109, BS EN 12390 |
| Internal Finish | Smooth, non-stick surface |
| Weight | Approximately 1/10 of metal cube moulds |
| Environmental Impact | Manufactured via eco-friendly, non-toxic process |
Applications
-
Concrete compressive strength testing
-
Quality control in construction materials
-
Cement factory laboratories
-
R&D and academic testing labs
-
On-site cube sampling for project QA/QC
-
Sustainable construction product testing
Models Available (Series Overview)
| Model No. | Cube Size | Description |
|---|---|---|
| AZA-CM-150P-OP / AZA1125 | 150 mm | One-piece plastic cube mould |
| AZA-CM-100P-OP | 100 mm | One-piece plastic cube mould |
| AZA-CM-050P-OP | 50 mm | One-piece micro cube mould |
Frequently Asked Questions (FAQ)
Q1: How is the AZA1125 different from traditional metal cube moulds?
It is significantly lighter, easier to handle, non-corrosive, and does not require assembly. No bolts or frames are needed.
Q2: How do I demould the specimen?
Use compressed air or water pressure to cleanly eject the cube after curing.
Q3: Is it reusable?
Yes. With proper cleaning and re-oiling, the mould can be reused many times.
Q4: Does it deform under vibration?
No. The mould is engineered to resist vibration, impact, and wear during compaction.
Q5: Is it environmentally friendly?
Yes. The mould is produced using a clean, non-polluting manufacturing process and is recyclable.
Additional information
| Construction |
One-piece hard plastic, precision-moulded |
|---|---|
| Sizes Available |
150mm, 100mm, and 50mm cube dimensions |
| Standards Compliance |
IS 516, ASTM C109, BS EN 12390 |
