DIST-86S SEMI-AUTOMATED DISTILLATION TESTER AZA1288
The AZA Lab Dist-86S Semi-Automated Distillation Tester AZA1288 is a precision-engineered petroleum testing instrument designed for accurate determination of the distillation characteristics of petroleum products and volatile organic liquids in full accordance with ASTM D86 standards.
Built for laboratories requiring dependable performance, repeatability, and operational safety, the AZA1288 combines intelligent semi-automation with operator flexibility. The system is ideally suited for petroleum refineries, fuel inspection laboratories, aviation fuel testing facilities, research institutions, petrochemical plants, and educational laboratories.
The instrument utilizes PID-controlled heating technology, precision temperature monitoring, and an integrated condenser cooling system to ensure highly stable distillation conditions and accurate boiling point determination across a wide range of petroleum fractions.
Description
APPLICATIONS
- Petroleum refineries
- Fuel testing laboratories
- Aviation fuel quality control
- Petrochemical plants
- Chemical and solvent manufacturers
- Inspection and certification agencies
- Academic and research institutions
- Industrial R&D laboratories
TEST METHODS
- ASTM D86 (Groups 0–4)
PRINCIPLE OF OPERATION
The AZA1288 determines the distillation characteristics of petroleum products by heating a measured sample under controlled conditions and recording the temperatures at which specific percentages of the sample evaporate.
The sample is heated in a borosilicate glass distillation flask using a PID-controlled heater. Generated vapors pass through a stainless-steel condenser and are collected in a graduated receiver chamber. The system accurately records critical temperature points including:
- Initial Boiling Point (IBP)
- 10% Recovery
- 50% Recovery
- 90% Recovery
- Final Boiling Point (FBP)
The integrated cooling system minimizes vapor loss and ensures stable condensate recovery throughout the test cycle.
SAFETY FEATURES
- Over-temperature protection
- Overfill detection system
- Condenser cooling failure alarm
- Receiver cooling deviation alerts
- Manual fire safety override
- Integrated ventilation support
- High-temperature resistant construction
- Electrical protection system
CONSTRUCTION FEATURES
- Powder-coated steel outer body
- Stainless-steel condenser assembly
- Heat-resistant borosilicate glassware
- Chemically resistant tubing and fittings
- Modular structure for easy servicing
- Compact benchtop footprint
TECHNICAL SPECIFICATIONS
| PARAMETER | SPECIFICATION |
|---|---|
| Model | AZA1288 |
| Product Type | Semi-Automated Distillation Tester |
| Test Method | ASTM D86 (Groups 0–4) |
| Automation Level | Semi-Automated |
| Heating Control | PID Controlled |
| Flask Capacity | 125 ml / 200 ml |
| Temperature Range | Ambient to 400 °C |
| Maximum System Range | Up to 450 °C |
| Temperature Accuracy | ±0.1 °C |
| Condenser Type | Stainless Steel with Circulating Cooling |
| Receiver Cooling | Integrated Automatic Cooling |
| Volume Measurement | Graduated Receiver |
| Display | Digital LCD |
| Data Output | USB |
| Safety Functions | Over-temp, overfill, cooling alerts |
| Power Supply | 230 V AC, 50 Hz |
| Dimensions | 420 × 320 × 580 mm |
| Approximate Weight | 18 kg |
SUITABLE SAMPLE TYPES
- Gasoline
- Diesel fuel
- Kerosene
- Aviation turbine fuel
- Aromatic hydrocarbons
- Solvents
- Light petroleum fractions
- Volatile organic liquids
STANDARD SUPPLY
- Main distillation unit
- Distillation flask
- Receiver cylinder
- Stainless-steel condenser assembly
- Temperature sensor
- Cooling connections
- Power cable
- User manual
OPTIONAL ACCESSORIES
- Additional distillation flasks
- Calibration thermometer
- External recirculating chiller
- Laboratory glassware kit
- LIMS integration support
- Spare condenser assembly
ADVANTAGES
- Accurate and repeatable distillation analysis
- Reduced operator variability
- Stable heating performance
- Enhanced laboratory safety
- Low maintenance requirements
- Reliable long-term operation
- Suitable for routine and research applications
- Excellent balance between automation and operator control
COMPLIANCE & APPLICABILITY
The AZA1288 is designed for precise distillation analysis of petroleum products and complies with internationally recognized ASTM D86 testing procedures. The system is suitable for quality assurance, product characterization, process monitoring, and regulatory testing applications across petroleum and petrochemical industries.
Additional information
| Test Method |
ASTM D86 (Groups 0–4) |
|---|---|
| Heating Control |
PID Controlled |
| Flask Capacity |
125 ml, 200 ml |
| Temperature Range |
Ambient to 400°C |
